Phoenix Contact 1897416 PCB connector QC 0,5/ 4-ST-3,81 Latest

Phoenix Contact 1897416 A PCB connector with a nominal cross section of 0.5 mm2 features a green color and is designed to handle a maximum current of 6 A at a rated voltage of 200 V. The contact surface is coated with Sn, while the connection type is socket, accommodating four potentials in a single row configuration. With a pitch of 3.81 mm, this connector utilizes a displacement connection method and can be plugged into a COMBICON MC 1.5 system without locking or mounting requirements; it is packaged in cardboard.
