Phoenix Contact 3002908 Feed-through terminal block UK 5 N OG Exclusive Offer

Phoenix Contact 3002908 Feed-through terminal block UK 5 N OG Exclusive Offer

Original price was: $3.05.Current price is: $1.52.

SKU: SK0061976-US20260519-084255 Category: Tag:

Description

Phoenix Contact 3002908 The feed-through terminal block has specific dimensions and connections, with a nominal voltage of 800 V and a maximum current capacity of 32 A. It features two connections made using a screw connection method, with rated cross-sections ranging from 0.2 mm² to 6 mm². The terminal block is mounted using type NS 35/7,5, NS 35/15, or NS 32 mounting types, and it has an orange coloration.

Specifications

Terminal Block Indication
No Indicator
Terminal Block Voltage Rating
800 Volt
Terminal Block Fused
Not Fused
Terminal Block Width
6.2 mm
Terminal Block Number of Levels
1
Terminal Block Number of Connections
2
Terminal Block Connection Method
Screw Connection
Terminal Block Grounded
Not Grounded
Terminal Block Min Wire Size
24
Terminal Block Max Wire Size
10
Terminal Block Component Color
Orange
Terminal Block Amperage
32 Amp
Component
Terminal Block
Manufacturer
Phoenix Contact
Sub Component
Feed-Through Terminal Block
